VSY720 Body-Ported

VSY720 Body-Ported

The Chanto VSY720 Series is an intermediate, body-ported pneumatic solenoid valve lineup engineered for modular systems requiring expanded flow capacities. Featuring structural thread connections bored directly into the valve block housing, it enables direct inline connection plumbing for larger rigid push-to-connect air line fittings without requiring a standalone sub-base manifold.
Built with a balanced internal sliding spool and precision pilot-actuated coils, these modular valves manage elevated air volumes swiftly while pulling minimal electrical wattage. They provide a high-throughput, decentralized fluid routing layout that can be mounted anywhere across an automated machinery frame.
Ardee Hi-Tech Pvt. Ltd. is the official and authorized dealer of Chanto products in India.

General Specifications

Valve Function Type: 5-Port, 2-Position (5/2-Way) or 5-Port, 3-Position (5/3-Way)

Fluid Medium: Filtered compressed air (lubricated or non-lubricated, 40-micron rating recommended)

Operating Pressure Range: 1.5 to 7.0 bar (0.15 to 0.7 MPa)

Ambient & Fluid Temperature: -5°C to 50°C (Prevent freezing conditions)

Standard Port Sizes: Direct G 1/8" or G 1/4" threaded body connection channels for straight line routing

Available Coil Voltages: DC 12V, DC 24V, AC 110V, AC 220V (50/60Hz options)

Electrical Entry Formats: L-plug or M-plug style quick-connect terminals with surge protection LEDs

Maximum Operating Frequency: Up to 4 cycles per second

Material

Main Valve Body: Premium heavy-duty anodized Aluminum Alloy for exceptional wear resistance

Internal Spool: Precision ground and polished Aluminum Alloy treated with a low-friction coating

Seals & O-Rings: Long-life Nitrile Butadiene Rubber (NBR) and resilient Viton elements

Pilot Guide Components: Corrosion-resistant Stainless Steel core armature sleeve and return springs

Solenoid Coil Housing: Glass-reinforced Thermoplastic resin encapsulation with high-grade copper windings

View full details

Product Knowledge

Areas of Application

Automotive Clamping Stations: Independent inline control of medium-bore pneumatic cylinders on welding jigs.

Material Conveying Chutes: Direct placement of isolated high-flow valves to actuate sorting gates and pusher mechanisms.

Food Packaging Lines: Standalone air blow-off circuits, lane diverters, and container positioning blocks.

Woodworking Machinery Automation: Powering independent alignment stops and heavy material clamping cylinders.

Textile Processing Networks: High-flow decentralized pneumatic routing loops across wide machine frames.

Part Numbers

CHANTO VSY720 Body-Ported

1. VSY720-1 Series (5/2 Way, Single Solenoid Body-Ported)
VSY720-1-A1-G-01 • VSY720-1-A2-G-01 • VSY720-1-D1-G-01 • VSY720-1-D2-G-01 • VSY720-1-A1-D-01 • VSY720-1-A2-D-01 • VSY720-1-D1-D-01 • VSY720-1-D2-D-01 • VSY720-1-A1-L-01 • VSY720-1-A2-L-01 • VSY720-1-D1-L-01 • VSY720-1-D2-L-01 • VSY720-1-A1-M-01 • VSY720-1-A2-M-01 • VSY720-1-D1-M-01 • VSY720-1-D2-M-01 • VSY720-1-A1-G-02 • VSY720-1-A2-G-02 • VSY720-1-D1-G-02 • VSY720-1-D2-G-02 • VSY720-1-A1-D-02 • VSY720-1-A2-D-02 • VSY720-1-D1-D-02 • VSY720-1-D2-D-02 • VSY720-1-A1-L-02 • VSY720-1-A2-L-02 • VSY720-1-D1-L-02 • VSY720-1-D2-L-02 • VSY720-1-A1-M-02 • VSY720-1-A2-M-02 • VSY720-1-D1-M-02 • VSY720-1-D2-M-02

2. VSY720-2 Series (5/2 Way, Double Solenoid Body-Ported)
VSY720-2-A1-G-01 • VSY720-2-A2-G-01 • VSY720-2-D1-G-01 • VSY720-2-D2-G-01 • VSY720-2-A1-D-01 • VSY720-2-A2-D-01 • VSY720-2-D1-D-01 • VSY720-2-D2-D-01 • VSY720-2-A1-L-01 • VSY720-2-A2-L-01 • VSY720-2-D1-L-01 • VSY720-2-D2-L-01 • VSY720-2-A1-M-01 • VSY720-2-A2-M-01 • VSY720-2-D1-M-01 • VSY720-2-D2-M-01 • VSY720-2-A1-G-02 • VSY720-2-A2-G-02 • VSY720-2-D1-G-02 • VSY720-2-D2-G-02 • VSY720-2-A1-D-02 • VSY720-2-A2-D-02 • VSY720-2-D1-D-02 • VSY720-2-D2-D-02 • VSY720-2-A1-L-02 • VSY720-2-A2-L-02 • VSY720-2-D1-L-02 • VSY720-2-D2-L-02 • VSY720-2-A1-M-02 • VSY720-2-A2-M-02 • VSY720-2-D1-M-02 • VSY720-2-D2-M-02

3. VSY720-3 Series (5/3 Way, Closed Center Body-Ported)
VSY720-3-A1-G-01 • VSY720-3-A2-G-01 • VSY720-3-D1-G-01 • VSY720-3-D2-G-01 • VSY720-3-A1-D-01 • VSY720-3-A2-D-01 • VSY720-3-D1-D-01 • VSY720-3-D2-D-01 • VSY720-3-A1-L-01 • VSY720-3-A2-L-01 • VSY720-3-D1-L-01 • VSY720-3-D2-L-01 • VSY720-3-A1-M-01 • VSY720-3-A2-M-01 • VSY720-3-D1-M-01 • VSY720-3-D2-M-01 • VSY720-3-A1-G-02 • VSY720-3-A2-G-02 • VSY720-3-D1-G-02 • VSY720-3-D2-G-02 • VSY720-3-A1-D-02 • VSY720-3-A2-D-02 • VSY720-3-D1-D-02 • VSY720-3-D2-D-02 • VSY720-3-A1-L-02 • VSY720-3-A2-L-02 • VSY720-3-D1-L-02 • VSY720-3-D2-L-02 • VSY720-3-A1-M-02 • VSY720-3-A2-M-02 • VSY720-3-D1-M-02 • VSY720-3-D2-M-02

4. VSY720-4 Series (5/3 Way, Exhaust Center Body-Ported)
VSY720-4-A1-G-01 • VSY720-4-A2-G-01 • VSY720-4-D1-G-01 • VSY720-4-D2-G-01 • VSY720-4-A1-D-01 • VSY720-4-A2-D-01 • VSY720-4-D1-D-01 • VSY720-4-D2-D-01 • VSY720-4-A1-L-01 • VSY720-4-A2-L-01 • VSY720-4-D1-L-01 • VSY720-4-D2-L-01 • VSY720-4-A1-M-01 • VSY720-4-A2-M-01 • VSY720-4-D1-M-01 • VSY720-4-D2-M-01 • VSY720-4-A1-G-02 • VSY720-4-A2-G-02 • VSY720-4-D1-G-02 • VSY720-4-D2-G-02 • VSY720-4-A1-D-02 • VSY720-4-A2-D-02 • VSY720-4-D1-D-02 • VSY720-4-D2-D-02 • VSY720-4-A1-L-02 • VSY720-4-A2-L-02 • VSY720-4-D1-L-02 • VSY720-4-D2-L-02 • VSY720-4-A1-M-02 • VSY720-4-A2-M-02 • VSY720-4-D1-M-02 • VSY720-4-D2-M-02

5. VSY720-5 Series (5/3 Way, Pressure Center Body-Ported)
VSY720-5-A1-G-01 • VSY720-5-A2-G-01 • VSY720-5-D1-G-01 • VSY720-5-D2-G-01 • VSY720-5-A1-D-01 • VSY720-5-A2-D-01 • VSY720-5-D1-D-01 • VSY720-5-D2-D-01 • VSY720-5-A1-L-01 • VSY720-5-A2-L-01 • VSY720-5-D1-L-01 • VSY720-5-D2-L-01 • VSY720-5-A1-M-01 • VSY720-5-A2-M-01 • VSY720-5-D1-M-01 • VSY720-5-D2-M-01 • VSY720-5-A1-G-02 • VSY720-5-A2-G-02 • VSY720-5-D1-G-02 • VSY720-5-D2-G-02 • VSY720-5-A1-D-02 • VSY720-5-A2-D-02 • VSY720-5-D1-D-02 • VSY720-5-D2-D-02 • VSY720-5-A1-L-02 • VSY720-5-A2-L-02 • VSY720-5-D1-L-02 • VSY720-5-D2-L-02 • VSY720-5-A1-M-02 • VSY720-5-A2-M-02 • VSY720-5-D1-M-02 • VSY720-5-D2-M-02
