Chanto

VEC3000 Series

VEC3000 Series

The Chanto VEC3000 Series is the highest-capacity family within Chanto’s compact pneumatic solenoid valve lineup, specifically engineered to deliver substantial air volume distribution while maintaining a highly restricted external envelope. Distributed across India by Ardee Hi-Tech Pvt. Ltd., the VEC3000 series solves the engineering challenge of driving larger, heavy-duty linear cylinders from tightly confined control cabinets or high-density manifold banks.
By integrating an optimized high-flow internal path with low-wattage miniature pilot coils, these valves maximize pneumatic throughput while minimizing heat generation and system electrical draw. They provide machine builders with an exceptionally reliable, space-saving solution for heavy-duty automation.

General Specifications

Valve Function Type: 5-Port, 2-Position (5/2-Way) or 5-Port, 3-Position (5/3-Way)

Fluid Medium: Filtered compressed air (lubricated or non-lubricated, 40-micron rating recommended)

Operating Pressure Range: 1.5 to 7.0 bar (0.15 to 0.7 MPa)

Ambient & Fluid Temperature: -5°C to 50°C (Prevent freezing conditions)

Standard Port Sizes: G 1/4" threaded main connection ports on specialized manifold sub-bases

Available Coil Voltages: DC 12V, DC 24V, AC 110V, AC 220V (50/60Hz configurations)

Electrical Entry Formats: Plug-in connector block with integrated surge protection LED or flying lead wires

Maximum Operating Frequency: Up to 4 cycles per second

Material

Main Valve Body: High-tensile precision extruded Aluminum Alloy (Anodized surface coating)

Internal Spool: Lightweight ground Aluminum Alloy treated with a low-friction wear compound

Seals & O-Rings: High-resiliency Nitrile Butadiene Rubber (NBR) and specialized HNBR composite seals

Pilot Guide Components: Corrosion-resistant Stainless Steel guide tubes and low-fatigue internal springs

Solenoid Coil Housing: Glass-reinforced Thermoplastic resin encapsulation with high-purity copper windings

View full details

Product Knowledge

Areas of Application

Medium-to-Heavy Packaging Lines: Actuating high-speed continuous box cartooning assemblies and large bag-sealing cylinders.

Multi-Station Assembly Manifolds: Centralized fluid routing arrays for manufacturing lines in automotive component plants.

Printing & Textile Machinery: Controlling heavy pneumatic tensioning systems, roll alignment guides, and material handling gates.

Conveyor Sortation Networks: Powering fast-acting high-impact divert gates and heavy package pushers.

Automated Process Test Benches: High-density integration into automated multi-actuator inspection equipment for non-fluid applications.

Part Numbers

CHANTO VEC3000 SERIES

1. VEC3100 Series (5/2 Way, Single Solenoid)
VEC3110-G • VEC3120-G • VEC3130-G • VEC3140-G
VEC3110-D • VEC3120-D • VEC3130-D • VEC3140-D
VEC3110-L • VEC3120-L • VEC3130-L • VEC3140-L
VEC3110-M • VEC3120-M • VEC3130-M • VEC3140-M

2. VEC3200 Series (5/2 Way, Double Solenoid)
VEC3210-G • VEC3220-G • VEC3230-G • VEC3240-G
VEC3210-D • VEC3220-D • VEC3230-D • VEC3240-D
VEC3210-L • VEC3220-L • VEC3230-L • VEC3240-L
VEC3210-M • VEC3220-M • VEC3230-M • VEC3240-M

3. VEC3300 Series (5/3 Way, Closed Center)
VEC3310-G • VEC3320-G • VEC3330-G • VEC3340-G
VEC3310-D • VEC3320-D • VEC3330-D • VEC3340-D
VEC3310-L • VEC3320-L • VEC3330-L • VEC3340-L
VEC3310-M • VEC3320-M • VEC3330-M • VEC3340-M

4. VEC3400 Series (5/3 Way, Exhaust Center)
VEC3410-G • VEC3420-G • VEC3430-G • VEC3440-G
VEC3410-D • VEC3420-D • VEC3430-D • VEC3440-D
VEC3410-L • VEC3420-L • VEC3430-L • VEC3440-L
VEC3410-M • VEC3420-M • VEC3430-M • VEC3440-M

5. VEC3500 Series (5/3 Way, Pressure Center)
VEC3510-G • VEC3520-G • VEC3530-G • VEC3540-G
VEC3510-D • VEC3520-D • VEC3530-D • VEC3540-D
VEC3510-L • VEC3520-L • VEC3530-L • VEC3540-L
VEC3510-M • VEC3520-M • VEC3530-M • VEC3540-M

6. VEC3600 Series (3/2 Way, Single Solenoid)
VEC3610-G • VEC3620-G • VEC3630-G • VEC3640-G
VEC3610-D • VEC3620-D • VEC3630-D • VEC3640-D
VEC3610-L • VEC3620-L • VEC3630-L • VEC3640-L
VEC3610-M • VEC3620-M • VEC3630-M • VEC3640-M
